CTFHD840 - HDMI 8.4" TFT - Touchscreen USB - Video - Autodimmer - Audio [LED]

CTFHD840 - HDMI 8.4" TFT - Touchscreen USB - Video - Autodimmer -  Audio [<b>LED</b>]
3D 360° View
  • LED-Backlight !
  • Audio speakers !
  • Auto-PowerOn !
  • High contrast !

New : LED-Backlight-Technology, with optimized color saturation enabling particular high and shining display. The scale of displayable color nuances is increased by 45% because of the new technology. Conventional LCDs are based on CCFL backlight, which can display approx. 72% of the standard color scale of NTSC (National Television Systems Committee). With LED-Backlight-Technology 104% of the NTSC-color scale can be displayed. This results in displaying in a highly realistic manner.

The new CTFHD-840 TFT-Display is the latest development from CarTFT.com and comes with many nice features. In any case it is the ideal display- and input-unit for your Laptop, CarPC or HTPC
[more]

Share

569.00 EUR
incl. 19% VAT, plus shipping
In Stock (10 pcs)

Add to cart
Compare
Front
Rear
Side
LCD Size 8.4"
Aspect Ratio 4:3
VGA resolutions 640x480-1920x1200
Native resolution 800x600
Dot resolution 2400x600
Brightness 450
VGA Input HDMI
Video Input 3x PAL/NTSC (RCA)
Audio Input 2x RCA (Stereo)
Touchscreen USB
Case color black
Power Input 12/24VDC
Power Consumption 10W
Case size 232 x 162 x 36 mm
Visible area 171 x 130 mm
Certificates CE, E1
Style On-Dash
yes Adjustable backlight
yes Auto Power-On
no Picture In Picture
yes IR Remote
no Headrest mount
yes TS pencil
no Earphone
yes Adjustable video aspect
yes Mirrorable video
yes Reverse camera input

New : LED-Backlight-Technology, with optimized color saturation enabling particular high and shining display. The scale of displayable color nuances is increased by 45% because of the new technology. Conventional LCDs are based on CCFL backlight, which can display approx. 72% of the standard color scale of NTSC (National Television Systems Committee). With LED-Backlight-Technology 104% of the NTSC-color scale can be displayed. This results in displaying in a highly realistic manner.

The new CTFHD-840 TFT-Display is the latest development from CarTFT.com and comes with many nice features. In any case it is the ideal display- and input-unit for your Laptop, CarPC or HTPC. With the touchscreen functionality you easily can control your PC. The briliant HDMI-display ensures a maximum readability and sharpness.

The device has among other features integrated speaker and an rear camera input.

AC-Adapter for home usage and a car cigarette lighter adapter is included as well as the IR-remote-control unit and the extra long (2,5 meters) All-In-One connector cable.

The CTFHD-840 can be used with any PC/MAC with HDMI- and USB port.

Driver-CD included, compatible with :
- Windows 95/98/ME/NT4/2000/XP/7/8/8.1/10
- XP Tablet PC Edition
- Windows CE 2.12, 3.0, .net
- Linux RedHat,Mandrake,..
- Macintosh OS 9.x, 10.x
- DOS,..




Spezifications
Screen size 8.4" digital
Aspect Ratio 4:3 wide TFT screen
Dot Resolution 2400x600= 1,440,000 dots
Physical Resolution 800x600
Supported Resolutions 640x480-1920x1080
Color configuration RGB stripe
Power input DC 12VDC
Power consumption max. 10W
Video system 3x Video inputs (PAL/NTSC)
1x HDMI input
Dimensions Display Case : 232mm x 162mm x 36mm
Display : 162 x 122 mm
Video input signal 1.0Vp-p, composite video
Brightness 450 cd/m² (on request also available as Ultra-variant with 1000 nits)
Contrast 600:1
Vibration IEC68-2-6
Operating Temperature -30° bis 85°C
Features Full function OSD control (englisch)
Built-in speaker
VESA compliant mounting holes (75mm) + metal rail
Auto Power On/Off
Auto-Dimmer
LED backlight
Automatic switching to rear camera (signal sensing on AV3)
What is included ? - 8.4" HDMI Touchscreen TFT with Video/Audio-support
- Infrared Remote Control
- Car dash mounting bracket
- Touchscreen pencil
- HDMI/Video/Audio/Touchscreen-cable (all-in-one !) 2,5 meters length
- Power Adapter f. EU 230V
- Cigarette Lighter Adapter
- Touchscreen Driver-CD
- Manual
Data sheet Download (PDF)
Data sheet [Energy efficiency class] Download (PDF)
